Note this item is for sale in the state of Oregon only.
Introducing the EG4 Power Pro ESS – A groundbreaking solution that brings together the capabilities of the EG4 18kPV All-In-One Hybrid Inverter and the EG4 Power Pro 14.3kWh Battery. Thanks to a modular design and integrated conduit box, this uniquely tailored kit seamlessly integrates advanced inverter technology and cutting-edge battery solutions, empowering you to harness, manage, and store solar energy specific to your needs.
Features:
Unmatched Performance
- Over 8000 cycles at 80% depth-of-discharge for a lasting energy solution
- Harness up to 12,000W continuous output with the EG4 18kPV inverter
- Closed-loop communication ensures precise energy coordination
- EG4 Power Pro 14.3kWh Battery delivers uninterrupted power
- Stack multiple EG4 18kPV units for enhanced power capacity
Enhanced Safety
- EG4 Power Pro features integrated self-heating for low-temperature resilience
- Perfect for outdoor applications, built to withstand various weather conditions
- Innovative total emergency stop function for safety and compliance
- Benefit from a 10-year warranty provided by EG4 Electronics
- Dual onboard fire arrestors ensure fail-safe protection
Streamlined Management
- EG4 18kPV eliminates the need for charge controllers or transformers
- Enjoy plug-and-play installation for immediate energy access
- Conduit box helps facilitate future system upgrades easily
- User-friendly LCD interface for intuitive system monitoring
- Manage energy from storage and grid simultaneously
Achieve Scalability
When relying on the internal integrated busbars, up to 3 batteries are supported in parallel when connected to a single inverter or 4 batteries in parallel when connected to 2 inverters, or up to 5 batteries in parallel when connected to 3 inverters. See section 8.2 in the PowerPro manual for more information.
Comprehensive Certifications
The EG4 18kPV is ETL & cETL certified and complies with national and international standards for safety and reliability when connected to the grid.
- Safety – UL1741SB Rule 21, RSD NEC 2020:690.12, AFCI NEC 2020:690.11 / UL1699B, GFDI NEC 2020:690.41(B), CSA 22.2.107.1, CSA 22.2.330
- EG4 Power Pro ESS holds UL9540 level certification
- Grid connection – IEEE 1547.1:2020;IEEE 1547:2018, Hawaii Rule 14H, California Rule 21 Phase I, II, III
- EMC – FCC Part 15 Class B
- Outdoor Rating – NEMA 4X / IP65
- CEC Solar Equipment Listing
***If you’ve purchased an EG4 18kPV Inverter through Signature Solar, be sure to use the customer code ‘Signature’ when setting up the monitoring system!
